Re: Let's see your finished DIY projects!

Postby eatyourguitar » Thu Sep 05, 2019 9:07 pm

jubal81 wrote:Image


is the blue electrolytic cap a non-polar (bipolar) type? why? what part of the circuit? is it vintage or just too big to SMD?
WWW.EATYOURGUITAR.COM <---- MY DIY STUFF
eatyourguitar

User avatar
IAMILF
IAMILF

Posts: 2861
Joined: Sun Oct 03, 2010 12:37 pm
Location: USA, RI

Re: Let's see your finished DIY projects!

Postby jubal81 » Fri Sep 06, 2019 1:17 am

eatyourguitar wrote:is the blue electrolytic cap a non-polar (bipolar) type? why? what part of the circuit? is it vintage or just too big to SMD?


It's a 10uF polarized electrolytic - the coupling cap on the input of the fuzz circuit. Since it's in the signal path, I stuck with 'lytic but chose a high-voltage cap for the big, axial vibe.

And thanks for all the kind words, guys. Worked on designing and building this since February, I think.
jubal81

User avatar
interested
interested

Posts: 10
Joined: Sat Mar 31, 2012 8:44 pm
Location: Evergreen State

Re: Let's see your finished DIY projects!

Postby fuzzonaut » Sat Sep 14, 2019 4:15 pm

Here's the PedalPCB version of the EQD/Sun O))) Life Pedal.

I didn't like the knob and footswitch layout too much. So, everything got moved, except the clipping switch and the boost foot switch, which explains the spaghetti wiring in there.

Sounds pretty good.


((O)) G.jpg



Now: https://glimmbrand.bandcamp.com / http://www.deepband.ch / https://fuzzonaut1.bandcamp.com / https://soundcloud.com/fuzzonaut-1
Then: https://suiciderat.bandcamp.com / Short Films: https://vimeo.com/user28594850
Good deals: wfs1234, Gigahearts_FX, stanimal, greyscales, hatshirt, insubordination, xrleroyx, HolySchnikes, nevada, skullservant, earthbound, chuckjaywalk, D.o.S., antennafarm, skip, hbombgraphics, UC, jwar, nieh, laekna, Rygot, D-Rainger, behndy, jero
fuzzonaut

User avatar
experienced
experienced

Posts: 768
Joined: Sat Aug 10, 2013 10:56 am
Location: Switzerland

Re: Let's see your finished DIY projects!

Postby Gigahearts_FX » Sat Sep 14, 2019 6:19 pm

Bad ass build
Agree the layout of the PCB isn’t great
Gigahearts_FX

User avatar
experienced
experienced

Posts: 957
Joined: Mon Feb 21, 2011 1:44 pm
Location: Manchester, UK

Re: Let's see your finished DIY projects!

Postby Gigahearts_FX » Sun Sep 15, 2019 1:20 am

Inspired by the fact that TGP have been slavering over this for some time, and the schematic is now out there
I have built a clone of the DRV on vero. Not built anything on vero for a long time, this went together ok - make a slight bodge which the keen eyed will see.

I must admit it sounds really good - doesnt have that sag that most normal Rats do. I appreciate some people like that, but I find it a bit bothersome.
Can't beleive the price these tend to go for - but seems the hype is somewhat justified, and they dont sell out in seconds now, so the scalping has died down a bit. Still, $250 for a Rat? Eash...

Because I wasnt bothered to save space this has gone in a 1790xx case ;D buffered bypass - apparently its a klon buffer but the parts values dont ring true to me from very distant memory... I could be wrong (!) 1983 because the original is 1981 and I was born in 1983 8)


Gigahearts_FX

User avatar
experienced
experienced

Posts: 957
Joined: Mon Feb 21, 2011 1:44 pm
Location: Manchester, UK
